Features
OUTPUT
RATED VOLTAGE: 12V
RATED CURRENT: 5A
CURRENT RANGE: 0 ÷ 5A
RATED POWER: 60W
VOLTAGE ADJUSTMENT RANGE [4]: 10.7 ÷ 13.5V
LINE REGULATION: ± 1%
LOAD REGULATION: ± 1%
VOLTAGE TOLERANCE [3]: ± 2%
RIPPLE & NOISE (max.) [2]: 240mVP-P
INPUT
VOLTAGE RANGE: 180 ÷ 264VAC
FREQUENCY RANGE: 47 ÷ 63Hz
EFFICIENCY (typ.): 84%
AC CURRENT (typ.): 0.7A/230VAC
INRUSH CURRENT (typ.): 40A / 230VAC(25°C)
LEAKAGE CURRENT (max.): 1mA / 230VAC
