Caratteristiche
OUTPUT
Rated Voltage: 12V
Rated Current: 11A
Current Range: 0 ÷ 11A
Rated Power: 132W
No Output Voltage (max.): 12.6V
Line Regulation: ± 1%
Load Regulation: ± 2%
Voltage Tolerance [3]: ± 5%
Ripple & Noise (max.) [2]: 300mVP-P
Setup, Rise Time [4]: max. 500ms, max. 50ms / 230VAC at full load
Hold up Time (typ.): 10ms / 230VAC at full load
INPUT
Voltage Range: 180 ÷ 264VAC
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.95 / 230VAC at full load
Efficiency (typ.): 90%
AC current (typ.): 0.7A / 230VAC
Inrush current (max.): 60A / 230VAC(25°C)
No Load Power Consumption (max.): 0.5W
