12,00€
Alimentatore 35W Single Output Switching Power Supply with PFC Function
OUTPUT
No Output DC Voltage: 32V
Rated Current: 10.5A
Rated Power: 33.6W
Voltage Range: 16 ÷ 32V
Line Regulation: ± 1%
Ripple & Noise (max.) [2]: 3.5VP-P
Setup, Rise Time[4]: 2000ms, 250ms/230VAC, 250ms/115VAC at full load
INPUT
Voltage Range: 90 ÷ 264VAC
Frequency Range: 47 ÷ 63Hz
Efficiency (typ.): 84%
AC current (typ.): 0.6A/115VAC; 0.3A/230VAC
Inrush Current: 65A/230VAC
Alimentatore 35W Single Output Switching Power Supply with PFC Function
• Constant current design
• Built-in active PFC function
• Universal AC input / Full range
• Protections: Short circuit
• Cooling by free air convection
• 100% full load burn-in test
• Isolation class II
• Fully encapsulated with IP67 level
GLSV-035B024
