13,90€
Alimentatore 60W Single Output Switching Power Supply with PFC Function
OUTPUT
No Output DC Voltage: 130V
Rated Current: 3.5A
Rated Power: 57W
Voltage Range: 78 ÷ 130V
Line Regulation: ± 1%
Ripple & Noise (max.) [2]: 5VP-P
Setup, Rise Time[4]: 2000ms, 250ms/230VAC; 3000ms, 250ms/115VAC at full load
INPUT
Voltage Range: 90 ÷ 264VAC
Frequency Range: 47 ÷ 63Hz
Efficiency (typ.): 87%
AC current (typ.): 1.2A/115VAC; 0.6A/230VAC
Inrush Current: 70A/230VAC, 35A/115VAC
Alimentatore 60W Single Output Switching Power Supply with PFC Function
• Constant current design
• Built-in active PFC function
• Universal AC input / Full range
• Protections: Short circuit
• Cooling by free air convection
• 100% full load burn-in test
• Isolation class II
• UL1310 Class 2 power unit, pass LPS
• Fully encapsulated with IP67 level
MFS-200-24-H-C
