Caratteristiche
OUTPUT
Rated Voltage: 24V
Constant Current Region [2]: 14.4 ÷ 24V
Rated Current: 13A
Rated Power: 320W
No Output Voltage (max.): 30V
Voltage Adjustment Range – Vadj potentiometer: 22 ÷ 27V
Current Adjustment Range – Iadj potentiometer: 6.7 ÷ 13.4A
Line Regulation: ± 1%
Load Regulation: ± 3%
Voltage Regulation [3]: ± 3%
Current Regulation [3]: ± 5%
Ripple & Noise (max.) [4]: 300mVP-P
Setup, Rise, Holdup time [5]: 500ms, 30ms, 30ms
INPUT
Voltage Range: 90 ÷ 305VAC
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.98 / 115VAC; PF > 0.95 / 230VAC at full load
Efficiency (typ.): 94%
AC current (typ.): 4A / 115VAC; 2A / 230VAC
Inrush current (max.): 45A / 230VAC(25°C)
