Caratteristiche
OUTPUT
Rated Voltage: 24V
Voltage Adjustment: 21.5 ÷ 26.5V
Rated Current: 6.5A
Current Range: 0 ÷ 6.5A
Rated Power: 156W
Line Regulation: ± 1%
Load Regulation: ± 1%
Voltage Tolerance [3]: ± 1%
Ripple & Noise (max.) [2]: 250mVP-P
Setup, Rise Time, at full load [4]: 500ms, 80ms / 230VAC
Hold up Time (typ.): 30ms / 230VAC at full load
INPUT
Voltage Range: 90 ÷ 132VAC, 180 ÷ 264VAC (selectable by switch)
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.6 / 230VAC at full load
Efficiency (typ.): 88%
AC current (typ.): 1.7A / 230VAC, 3.0A / 115VAC
Inrush current (max.): 1.2A / 230VAC 60A / 230VAC(25°C)
No Load Power Consumption (max.): 0.5W
