Caratteristiche
OUTPUT
Rated Voltage: 12V
Voltage Adjustment: 11.0 ÷ 13.0V
Rated Current: 3A
Current Range: 0 ÷ 3A
Rated Power: 36W
Line Regulation: ± 0.5%
Load Regulation: ± 0.5%
Voltage Tolerance [3]: ± 1%
Ripple & Noise (max.) [2]: 120mVP-P
Setup, Rise Time [4]: 1000ms, 35ms / 230VAC
Hold up Time (typ.): 30ms / 230VAC at full load
INPUT
Voltage Range: 90 ÷ 264VAC
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.6 / 230VAC at full load
Efficiency (typ.): 86%
AC current (typ.): 0.42A / 230VAC
Inrush current (max.): 45A / 230VAC(25°C)
No Load Power Consumption (max.): 0.2W
