Features
OUTPUT
Rated Voltage: 24V
Rated Current: 1.7A
Current Range: 0 ÷ 1.7A
Rated Power: 40W
No Output Voltage (max.): 25.2V
Voltage Adjustment Range [6]: 23 – 29V
Line Regulation: ± 0.5%
Load Regulation: ± 1%
Voltage Tolerance [3]: ± 5%
Ripple & Noise (max.) [2]: 400mVP-P
Setup, Rise Time [4]: max. 550ms, max. 15ms / 230VAC at full load
Hold up Time (typ.): 55ms / 230VAC at full load
INPUT
Voltage Range: 90 ÷ 264VAC
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.5/ 230VAC at full load
Efficiency (typ.): 82%
AC current (typ.): 0.4A / 230VAC, 0.7A / 115VAC,
Inrush current (max.): 60A / 230VAC(25°C)
No Load Power Consumption (max.): 1W
