Caratteristiche
OUTPUT
Rated voltage: 12V
Rated current: 11A
Power range: 0 ÷ 11W
Rated power: 132W
No Output Voltage (max.): 12.6V
Line regulation: ± 1%
Load regulation: ± 2%
Voltage tolerance [3]: ± 5%
Ripple & noise (max.) [2]:360mVP-P
Setup, Rise Time [4]: 300ms, 100ms / 230VAC at full load
Hold up Time (typ.): 10ms / 230VAC at full load
INPUT
Voltage range: 198 ÷ 264VAC
Frequency range: 47 ÷ 63Hz
Power factor (typ.): PF > 0.97 / 230VAC at full load
Efficient (typ.): 93%
Ac current (typ.): 1.0A / 230VAC
Inrush current (max.): 82A / 230VAC(25°C)
No Load Power Consumption (max.): 0.5W
