Caratteristiche
OUTPUT
Rated Voltage: 24V
Rated Current: 4.0A
Current Range: 0 ÷ 4.0A
Rated Power: 96W
No Output Voltage (max.): 25.2V
Voltage Adjustment Range (SVR1) 23 ÷ 28V
Line Regulation: ± 0.5%
Load Regulation: ± 1%
Voltage Tolerance [3]: ± 5%
Ripple & Noise (max.) [2]: 200mVP-P
Setup, Rise Time [4]: max. 400ms, max. 100ms / 230VAC at full load
Hold up Time (typ.): 50ms / 230VAC at full load
INPUT
Voltage Range: 90 ÷ 264VAC
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.9 / 230VAC at full load
Efficiency (typ.): 85%
AC current (typ.): 0.75A / 230VAC, 1.5A / 115VAC,
Inrush current (max.): 90A / 230VAC(25°C)
No Load Power Consumption (max.): 2.0W
