Caratteristiche
OUTPUT
Rated Voltage: 12V
Constant Current Region [2]: 6 ÷ 12V
Rated Current: 3.3A
Rated Power: 39.6W
No Output Voltage (max.): 15V
Voltage Adjustment Range – Vadj potentiometer: 10 ÷ 13.5V
Current Adjustment Range – Iadj potentiometer: 2.2 ÷ 3.3A
Line Regulation: ± 1%
Load Regulation: ± 3%
Voltage Tolerance [3]: ± 3%
Current Tolerance [3]: ± 5%
Ripple & Noise (max.) [4]: 350mVP-P
Setup, Rise, Holdup time [5]: 500ms, 30ms, 15ms
INPUT
Voltage Range: 90 ÷ 305VAC
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.98 / 115VAC; PF > 0.95 / 230VAC at full load
Efficiency (typ.): 87%
AC current (typ.): 0.55A / 115VAC; 0.22A / 230VAC
Inrush current (max.): 60A / 230VAC(25°C)
