Caratteristiche
OUTPUT
Rated Voltage: 24V
Rated Current: 6.25A
Current Range: 0 ÷ 6.25A
Rated Power: 150W
No Output Voltage (max.): 25.2V
Line Regulation: ± 0.5%
Load Regulation: ± 1%
Voltage Tolerance [3]: ± 3%
Ripple & Noise (max.) [2]: 250mVP-P
Setup, Rise Time [4]: 500ms, 50ms / 230VAC at full load
Hold up Time (typ.): 5ms / 230VAC at full load
INPUT
Voltage Range: 200 ÷ 240VAC
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.9 / 230VAC at full load
Efficiency (typ.): 90%
AC current (typ.): 0.85A / 230VAC
Inrush current (max.): 75A / 230VAC(25°C)
No Load Power Consumption (max.): < 0.25W
