Caratteristiche
OUTPUT
Rated voltage: 12V
Rated current: 15A
Power range: 0 ÷ 15W
Rated power: 180W
No Output Voltage (max.): 12.6V
Line regulation: ± 1%
Load regulation: ± 2%
Voltage tolerance [3]: ± 5%
Ripple & noise (max.) [2]:300mVP-P
Setup, Rise Time [4]: 500ms, 50ms / 230VAC at full load
Hold up Time (typ.): 10ms / 230VAC at full load
INPUT
Voltage range: 180 ÷ 264VAC
Frequency range: 47 ÷ 63Hz
Power factor (typ.): PF > 0.95 / 230VAC at full load
Efficient (typ.): 92%
Ac current (typ.): 1.5A / 230VAC
Inrush current (max.): 75A / 230VAC(25°C)
No Load Power Consumption (max.): 0.21W
