10,20€
Alimentatore 35W Single Output Switching Power Supply_Plastic Case
OUTPUT
Rated Voltage: 36V
Rated Current: 1A
Rated Power: 36W
Line Regulation: ± 1%
Load Regulation: ± 2%
Ripple & Noise (max.) [2]: 300mVP-P
Setup, Rise Time[4]: 3000ms, 250ms/115VAC; 5000ms,250ms/230VAC at full load
INPUT
Voltage Range: 90 ÷ 264VAC
Frequency Range: 47 ÷ 63Hz
Efficiency (typ.): 85%
AC current (typ.): 0.35A/115VAC; 0.70A/230VAC
Inrush Current: 70A/230VAC,35A/115VAC
Alimentatore 35W Single Output Switching Power Supply
• Constant voltage design
• Universal AC input / Full range
• Protections: Short circuit / Over current / Over voltage
• Cooling by free air convection
• Isolation class II
• Class 2 power unit
• Fully encapsulated with IP67 level [5]
GPV-60-15
