Caratteristiche
OUTPUT
Rated Voltage: 12V
Constant Current Region [2]: 6 ÷ 12V
Rated Current: 40A
Rated Power: 480W
No Output Voltage (max.): 14V
Voltage Adjustment Range – potentiometer: 10.2 ÷ 12.6V
Current Adjustment Range – potentiometer: 20 ÷ 40A
Line Regulation: ± 1%
Load Regulation: ± 3%
Voltage Regulation [3]: ± 3%
Current Regulation [3]: ± 5%
Ripple & Noise (max.) [4]: 150mVP-P
Setup, Rise, Holdup time [5]: 500ms, 30ms, 30ms
INPUT
Voltage Range: 108 ÷ 305VAC
Frequency Range: 47 ÷ 63Hz
Power Factor (typ.): PF > 0.98 / 115VAC; PF > 0.95 / 230VAC at full load
Efficiency (typ.): 93%
AC current (typ.): 6A / 115VAC; 3A / 230VAC
Inrush current (max.): 55A / 230VAC(25°C)
